9
Messages that can be transmitted and received
With the factory settings, the following MIDI messages can be transmitted and received.
Data operations transmitted
MIDI messages transmitted
ON/OFF key settings transmitted
Touch pad X-axis Effect control 1 (CC#12) *1, *2 Program Memory 4
Touch pad Y-axis Modulation depth 1 (CC#1) Y=5–9 Program Memory 1
Modulation depth 2 (CC#2) Y=5–1 Program Memory 2
Effect control 2 (CC#13) *1, *2 Program Memory 5
Touch pad X+Y-axis Effect depth 3 (CC#93) *1 Program Memory 3
Touch pad on/off Effect depth 2 (CC#92) *1, *2 Program Memory 6
FX DEPTH Effect depth 4 (CC# 94) *1, *2 Program Memory 7
MUTE Effect depth 5 (CC# 95) *1, *2 Program Memory 8
Program change Program change (00–99) *2 Hold
Data operations received
MIDI messages received
ON/OFF key settings received
Touch pad X-axis Effect control 1 (CC#12) *1, *2 Program Memory 4
Touch pad Y-axis Effect control 2 (CC#13) *1, *2 Program Memory 5
Touch pad on/off Effect depth 2 (CC#92) *1, *2 Program Memory 6
FX DEPTH Effect depth 4 (CC# 94) *1, *2 Program Memory 7
MUTE Effect depth 5 (CC# 95) *1, *2 Program Memory 8
Program change Program change (00–99) *2 Hold
BPM Timing clock Sample 1
*1: The MIDI messages transmitted and received can be changed in a range of CC#1–CC#31,
CC#64–CC#95, and PITCH BEND. ( ) is the factory setting.
*2: Ena/Dis and CC# settings are the same for both transmission and reception.
The control changes for touch pad Y-axis Y-5–9 and Y-5–1, and for touch pad X+Y axis can be trans-
mitted but not received. For this reason when you record control changes into a sequencer, use MIDI Edit
mode to turn PROGRAM MEMORY 1–3 off, so that unnecessary MIDI messages are not transmitted.
Previously-specified control numbers cannot be specified again elsewhere.
Specifications
Number of programs: 100
Input: Mic input jack / monaural phone jack, Phono input jacks / RCA phono jacks, Line input
jacks / RCA phono jacks
Output: Line output jacks / RCA phono jacks, Headphone jack / stereo phone jack
MIDI: IN, OUT
Power supply: DC 12V, 700 mA
Included items: AC adapter, touch pad protection sheet
Weight: 1.1kg
Dimensions: 204(W) X 207(D) X 48(H)mm
— Appearance and specifications are subject to change without notice for improvement.
