23
Controllers available in External Control mode
You can use the following controllers in External Control mode.
Controller Transmitted MIDI message (factory settings)
Touch pad X-axis (entire range) Control change (#70)
Touch pad Y-axis (entire range) Control change (#71)
Touch pad X-axis (right of center) Control change (#72)
Touch pad X-axis (left of center) Control change (#73)
Touch pad Y-axis (middle to top) Control change (#74)
Touch pad Y-axis (middle to bottom) Control change (#75)
Touch pad XY-axes (lower left to upper right) Control change (#76)
Touch pad on/off Control change (#92)
LEVEL slider Control change (#93)
FX DEPTH knob Control change (#94)
HOLD button Control change (#95)
PROGRAM MEMORY 1 button Control change (#49)
PROGRAM MEMORY 2 button Control change (#50)
PROGRAM MEMORY 3 button Control change (#51)
PROGRAM MEMORY 4 button Control change (#52)
PROGRAM MEMORY 5 button Control change (#53)
PROGRAM MEMORY 6 button Control change (#54)
PROGRAM MEMORY 7 button Control change (#55)
PROGRAM MEMORY 8 button Control change (#56)
SAMPLE BANK A button Note on/off (#36)
SAMPLE BANK B button Note on/off (#37)
SAMPLE BANK C button Note on/off (#38)
SAMPLE BANK D button Note on/off (#39)
PROGRAM/BPM knob Program change (#0–#127), Timing clock
Messages that can be transmitted/received outside of External Control mode
With the factory settings, the following MIDI messages can be transmitted and received.
Controller
MIDI messages transmitted and received (factory settings)
Touch pad X-axis Control change (#12)
Touch pad Y-axis Control change (#13)
Touch pad on/off Control change (#92)
LEVEL slider Control change (#93)
FX DEPTH knob Control change (#94)
HOLD button Control change (#95)
SAMPLE BANK A button Note on/off (#36)
SAMPLE BANK B button Note on/off (#37)
SAMPLE BANK C button Note on/off (#38)
SAMPLE BANK D button Note on/off (#39)
PROGRAM/BPM knob Program change, bank select, MIDI timing clock (only if
the clock setting is Int)
