KORG monologue Parts List : SAFETY CRITICAL COMPONENT.
Assem=Assembly view item number
-SV -RD -GD -BL -BK
510100521010 FUSE FUSE TF16AT2.00TTD KLM-3621 [TOP]FU1
510300511035 POWER MOS FET RRQ030P03TR KLM-3621 [TOP]F1, F2
510310511501 DIODE 1SR154-400 TE25 (PMDS) (S) KLM-3621 [TOP]D3
510312513021 Chip LED TO-1608BC-MRE KLM-3621 [TOP]LED1
510320511003 OPAMP NJM4580M-TE3-#ZZZB (S) KLM-3621 [TOP]IC10
510320511008 OPAMP NJM4556AM-TE1-#ZZZB (S) KLM-3621 [TOP]IC18
510320511049 OPAMP NJM13700M-TE1-#ZZZB(S) KLM-3621 [TOP]IC22
510320514030 RESET IC BU4227G-TR KLM-3621 [BOT]IC28
510320516126 DC-DC Converter TPS62112RSAR KLM-3621 [TOP]IC4, IC5
510320516175 LDO IC TLV70033DCKR KLM-3621 [TOP]IC13 [BOT]IC29
510320519535 OPAMP TL084CPT KLM-3621 [TOP]IC6, IC8, IC17, IC21, IC24
510330510002 PHOTO COUPLER TLP2368(TLMIDI,E(0 KLM-3621 [TOP]PC1
510335522030 CRYSTAL RSD-04000F202000 KLM-3621 [TOP]X1, X2
510374510004 SW PS-22F03 (NON-LOCKED) KLM-3621 [TOP]SW1
510450520014 PHONE JACK PJ-603AG-04 (D) KLM-3621 [TOP]PH1, PH2, PH3
510450520506 DIN JACK DS-05-02(DIN5P W/OUT SW) (D) KLM-3621 [TOP]DIN1, DIN2
510450524506 PHONE JACK LJE0371-4P KLM-3621 [TOP]PH4, PH5
510450524509 DC JACK LD-0214 KLM-3621 [TOP]DJ1
510474527501 USB CONNECTOR QT-6301-004 KLM-3621 [TOP]USB1
510320516230 OPAMP TL064CPWR KLM-3621 [TOP]IC11, IC12, IC15, IC19, IC20, IC23, IC27
510C93523621 CIRCUIT ASS'Y BOARD KLM-3612 ASSY(DATA) MONOLOGUE KLM-3621
510200515516 VARISTOR AVR-M1608C120MT6AB KLM-3622 [TOP]VZ1, VZ2, VZ3, VZ4, VZ5, VZ6, VZ7
510312513021 Chip LED TO-1608BC-MRE KLM-3622
[TOP]LED1, LED2, LED3, LED4, LED5, LED6, LED7, LED8,
LED9, LED10, LED11, LED12, LED13, LED14, LED15,
LED16, LED17, LED18, LED19, LED20, LED21, LED22,
LED23, LED24, LED25, LED26, LED27, LED28, LED29,
LED30, LED31, LED32, LED33
510313504002 EL DISPLAY UG-2864HSWEG01 KLM-3622 [BOT]OLED1
510320516175 LDO IC TLV70033DCKR KLM-3622 [TOP]IC1
510360524044 ROTARY VR F16K-1467A KLM-3622
[TOP]VR1, VR2, VR3, VR4, VR5, VR6, VR7, VR8, VR9,
VR10, VR11, VR12, VR13, VR14, VR15
510360524045 ROTARY ENCODER F11E-0184A KLM-3622 [TOP]EC1
510374520021 TACT SW SKRGAQD010 KLM-3622
[TOP]SW10, SW12, SW13, SW14, SW15, SW16, SW17,
SW18, SW20, SW21, SW22, SW23, SW24, SW25, SW26,
SW27, SW28, SW29, SW30, SW31, SW32, SW33, SW34,
SW35
510374522024 TOGGLE SW TS-23E02-AC18-NI KLM-3622 [TOP]SW2, SW19
510374522028 TOGGLE SW TS-23E01-AC-18-NI KLM-3622
[TOP]SW1, SW3, SW4, SW5, SW6, SW7, SW8, SW9,
SW11
510374524034 SLIDE VR RA45D1F-211-15C1-B5K-0046 KLM-3622 [TOP]VR16
510C93523622 CIRCUIT ASS'Y BOARD KLM-3622/23 ASSY MONOLOGUE
510476801502 HARNESS HNS-4674 10pin
510476801503 HARNESS HNS-4677 7pin
510476801504 HARNESS HNS-4673 16pin
510476801505 HARNESS HNS-4675 3pin
510476801506 HARNESS HNS-4676 2pin
510646800192 X-15230 LOWER CASE E10340 Mechanical
510645800176 X-15230 BACK BOARD D30535 Mechanical
510646800171 X-13290 BEND BRACKET E30756 Mechanical
510640805027 X-13290 BEND SPRING C41846 Mechanical
510646800193 X-15230 MOLD CHASSIS E20459 Mechanical
510646800175 X-13290 WINDOW E30768 Mechanical
510646800176 X-13290 LED REFRECTOR E40933 Mechanical
510646502426 X-12500 BATTERY COVER E30288-5 Mechanical
510640805031 X-15230 BATTERY SPRING(+) C41921 Mechanical
510640805032 X-15230 BATTERY SPRING(-) C41922 Mechanical
510640800203 BATTERY SPRING (W)VN C41729 Mechanical
510640800510 X-15230 UPPER PANEL C10295-1 Mechanical 1
510640800511 X-15230 UPPER PANEL C10295-2 BK Mechanical 1
510640800512 X-15230 UPPER PANEL C10295-3 BL Mechanical 1
510640800513 X-15230 UPPER PANEL C10295-4 GD Mechanical 1
510640800514 X-15230 UPPER PANEL C10295-5 RD Mechanical 1
510646800177 X-13290 BEND KNOB E30749 Mechanical
510646800179 X-13290 TEMPO KNOB E30731 Mechanical
510646800180 X-13290 VOL KNOB E30730 Mechanical
510500501515 X-5500 SWITCH MASK KOC-F41307 Mechanical
510646502163 X-6140 PSW KNOB KOC-E40774 Mechanical
510802500558 FRAME LEGS F41516 Mechanical
510700503541 SCREW X-3230 CAP SCREW KOC-C41316 Mechanical
510700503712 SCREW BT CAP NIC 2.6X6 KOC-C41928 Mechanical 12 12
510700503713 SCREW BT CAP 3BBC 2.6X6 KOC-C41928-2 Mechanical 12 12 12
510D93523619 CIRCUIT ASS'Y BOARD KEYBOARD UNIT LMK-25 KLM-3619 Keyboard Parts
510646502364 LMK SYNTH 12KEY ASSY H30424-1 Keyboard Parts
510646502468 LMK Synth 5 Key Assy KOC-H30424-4 Keyboard Parts
510646502469 LMK Synth 7 Key Assy KOC-H30424-5 Keyboard Parts
510646502470 LMK Synth CC Key KOC-H30422-6 Keyboard Parts
510500507108 LMK Rubber Button 12 KOC-E30630-2 Keyboard Parts
510500505576 LMK-25 KB Felt KOC-F42150 Keyboard Parts
510500505577 LMK-25 Upper Limit Felt KOC-F42151 Keyboard Parts
QTY
Code Category Part Name Description Remark
1
2
1
1
1
1
1
1
2
2
5
1
2
1
3
2
2
1
1
7
1
7
33
1
1
15
1
1
24
2
9
1
1
1
1
9/7
1
1
3
1
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
15
11
1
1
1
