Connecting a Pa-Series instrument to an external controller |27
2 Make the external controller control Brightness on the X-axis, Resonance on
the Y-axis.
Still in the X-Y Pad page, program the X/Y pad. Assign to the X-axis CC#74
(corresponding to the Brightness parameter), to the Y-axis CC#71 (corre-
sponding to the Resonance parameter).
3 After having edited the parameters, press the Write button to save the set-
ting in the controller’s memory. Then press the Close button to close the
dialog.
Connect the devices
4 Connect the USB or MIDI OUT port of the external controller to the USB
HOST or MIDI IN port of the Pa-Series instrument. Be sure the external con-
troller’s USB port is enabled.
USB HOST USB
(TO HOST/DEVICE)
MIDI IN MIDI OUT
To Next Page
