Korg Pa5X User Manual

The front panel |9
English
Overview of the
instrument
The front panel
The front panel is where you can find the instrument’s controls.
Music stand
A music stand is included with your Pa5X.
PaAS amplification system
You can install the (optional) PaAS amplification system. When installed, control
the output volume of the speakers via the MASTER VOLUME slider.
The speakers are automatically deactivated when connecting the headphones.
You can also manually deactivate them by deselecting the Speakers checkbox in
the Settings > Audio/Video > MP3/Speakers page.
Headphones connector
Connect a pair of headphones to this output. You can use headphones with an
impedance of 16-200 Ohms (50 Ohms suggested).
Keyboard
Use the keyboard to play notes and chords. Depending on the status of the SPLIT
indicator, the keyboard may be joint or split between different sounds.

Korg Pa5X Specifications

General

Type	Arranger Keyboard
Keys	61 or 76
Aftertouch	Yes
Polyphony	160 voices
Key Action	Semi-weighted
Sound Engine	EDS-XP
Drum Kits	More than 130 Drum Kits
User Memory	4GB PCM
Styles	Over 600
Display	8-inch color TouchView display
Sequencer	16-track MIDI sequencer
Audio Inputs	2 x Mic/Line (XLR/TRS combo), Guitar (TS)
Headphones	1 x 1/4"
MIDI	In/Out/Thru
USB	Type A and B
Storage	MicroSD slot
Speakers	Optional
Weight	Varies by model
