Korg SP-170S Service Manual

KORG SP-170S Digital Piano Parts List
* part is common with SP170.
Part Number
Category
Part Name
Location
Reference
QTY
510320514030
RESET IC
BU4227G-TR
[TOP] IC5
1
510320514038
REGULATOR IC
BA00DD0WHFP-TR
[TOP] IC18
1
510320514043
RESET IC
BU4813G-TR
[TOP] IC19
1
510320516106
D/A Converter
PCM1754DBQR
[TOP] IC13
1
510320516110
REGULATOR IC
TPS73701DCQ
[TOP] IC16
1
510320516111
REGULATOR IC
TPS73733DCQ
[TOP] IC15
1
510320516112
REGULATOR IC
UA78L05AIPK
[TOP] IC12
1
510324021160
OPAMP
NE5532DR (TS)
[TOP] IC17
1
510335522003
CRYSTAL
HC49/USM4-024M576000BR
[TOP] X1
1
510C80783021
PC ASSY
KLM-3021ASSY (SP-170S)
1
510306510503
POWER MOS FET
SI4431CDY-T1-E3
F1
1
510320511008
OPAMP
NJM4556AM-TE1-#ZZZB (S)
IC5-6
2
510320516109
POWER AMP IC
TPA3101D2PHP
IC4
1
510320516112
REGULATOR IC
UA78L05AIPK
IC1
1
510450520017
PHONE JACK
PJ-603A-02
PH1
1
510450528003
DC JACK
LGP-6531-0800F
DJ1
1
510450520506
DIN JACK
DS-05-02(DIN5P W/OUT SW ) (D)
MIDI1
1
510450520512
PHONE JACK
EJS-7-1535
PH2-3
2
510312524502
LED
CL-333SRD/F2
LED1
1
510476501032
HARNESS
HNS-4016 (AMP-LED)
CN6B
1
510C80783067
PC ASSY
KLM-3067/8 ASSY (SP-170S)
1
510360520044
VR
RK11K1140A9L
1
510374520026
TACT SW
SKRGAED010
3
510C80783061
PC ASSY
KLM-3061ASSY (SP-170S)
1
510476501027
HARNESS
HNS-4011(MAIN-AMP)
1
510476501060
HARNESS
HNS-4107(MAIN-AMP2)
1
510476501061
HARNESS
HNS-4108(MAIN-RH4)
1
510476501030
HARNESS
HNS-4014(AMP-SP)
1
510476501062
HARNESS
HNS-4098(PANEL - MAIN)
1
510476501063
HARNESS
HNS-4099(PANEL - JACK)
1
510C9017
KEYBOARD UNIT
RH-4 KEYBOARD UNIT
1
510410524002
Speaker
C112P01K0000
2
510500505555
X-08311BK PanelPlate F41637-1
BK,RD
510500505556
X-08311WH PanelPlate F41637-2
WH
510646508019
X-08310BK SP NET L E30538-1
BK,RD
510646508021
X-08310WH SP NET L E30538-3
WH
510646508020
X-08310BK SP NET R E30538-2
BK,RD
510646508022
X-08310WH SP NET R E30538-4
WH
510646502018
X-1200/10 VR-KNOB-L KOC-E30313
1
510646508522
08311 CIRCLE SW NL LG E40724-2
3
510640520509
STAND SUPPORT PLATE C41657
2
510646508023
X-08310BK MUSIC STAND E30539-1
BK
510646508024
X-08310WH MUSIC STAND E30539-2
WH
510646508026
X08310RD MUSIC STAND E30539-3
RD
510C9018
PEDAL PS-3
X-0831S
1
500405016600
AC ADAPTER
KA310EUP II:DSA-20D-12 2120180
1
500600006513
AC CABLE
DC-1800-DO2LY(PSE)
500600006510
AC CABLE
UC-1800-UO2LY(UL/NISPT2)(W/PB)
500600006509
AC CABLE
EC-1800-E02LY(VDE) (W/POLYBAG)
510600006512
AC CABLE
SC-1800-SO2LY(SAA)
510600006511
AC CABLE
BC-1800-BO2LY(BS) (W/POLYBAG)
510600540504
AC CABLE
CC-1800-C02LY(CCC)
1
1
1
1
1

Korg SP-170S Specifications

General

Keyboard	88-key (A0–C8), Natural Weighted Hammer Action (NH)
Amplifier Output	9 W x 2
Power Supply	DC 12 V
Power Consumption	9 W
Touch Control	Light, Normal, Heavy
Polyphony	120 voices
Sounds	10 sounds
Effects	Reverb, Chorus
Demo Songs	10 songs
Metronome	Yes (adjustable tempo and beat)
Transpose	Yes
Tuning	Yes
Pedal	Damper Pedal (included)
Connectors	Headphone (x2)
Included Accessories	AC adapter, Damper Pedal, Music stand
Sound Generation	Stereo Sampling
