4. Making connections
Before you make connections, be sure to turn off the power of your other equipment, or turn the volume down to
zero. Connecting cables are sold separately.
INPUT
OUTPUT/PHONES
DC9V
Hard disk recorder etc.
Audio system
Guitar amp / powered monitor (*1)
Mono 1/4" jack - mono 1/4" jack
Headphones (*1)
AC adapter (*2) to AC outlet
Mono 1/4" jack - mono 1/4" jack
Mono output - mono 1/4" jack/stereo
output - two mono 1/4" jacks
Stereo 1/4" jack - stereo RCA
(phone) jack
Guitar
*1: The OUTPUT/PHONES jack is a stereo output. If you use a mono phone cable to connect the AX1G to a
guitar amp, only the L (left) sound will be output.
*2: If you use batteries, the AC adapter is not necessary. If you use an AC adapter, be sure to use only the
specified model (DC9V
).
