TRITON pro Parts List Ver1.00
Parts code Parts name and Spesfication PCB No. Unit Price(Yen)
471102050 CONNECTOR TOP SJ20-05WX KLM-2083 10
471102050 CONNECTOR TOP SJ20-05WX KLM-2084 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2084 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2085 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2089 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2083 10
471102070 CONNECTOR TOP SJ20-07WX KLM-2083 10
471102070 CONNECTOR TOP SJ20-07WX KLM-2089 10
471102080 CONNECTOR TOP SJ20-08WX KLM-2083 10
471102090 CONNECTOR TOP SJ20-09WX KLM-2083 10
471102100 CONNECTOR TOP SJ20-10WX KLM-2089 10
471102110 CONNECTOR TOP SJ20-11WX KLM-2085 10
471102110 CONNECTOR TOP SJ20-11WX KLM-2089 10
471102110 CONNECTOR TOP SJ20-11WX KLM-2086 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2091 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2083 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2085 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2089 10
471102140 CONNECTOR TOP SJ20-14WX KLM-2084 10
471102140 CONNECTOR TOP SJ20-14WX KLM-2089 10
471102140 CONNECTOR TOP SJ20-14WX KLM-2083 10
471102150 CONNECTOR TOP SJ20-15WX KLM-2085 10
471102150 CONNECTOR TOP SJ20-15WX KLM-2089 10
471102160 CONNECTOR TOP SJ20-16WX KLM-2086 10
471102160 CONNECTOR TOP SJ20-16WX KLM-2089 10
472092060 CONNECTOR SIDE SJ20-06WM KLM-1828 10
472092090 CONNECTOR SIDE SJ20-09WM KLM-1828 10
472093150 CONNECTOR SIDE SB20-15WL KLM-1827 10
474020600 CONNECTOR 52080-0510 KLM-1828 30
474021000 CONNECTOR 34P 5332-34T2 KLM-2083 60
474021200 CONNECTOR 40P 5332-40GS1 KLM-2083 90
474021300 DIN CONNECTOR TC7927-28-401 KLM-2084 60
474028600 CONNECTOR IL-G-4P-S3T2-SA KLM-2091 20
474028700 CONNECTOR 08FDZ-ST-BHL KLM-2085 50
474028800 CONNECTOR 008370-141-000-800 KLM-2091 40
474028900 SIMM CONNECTOR 52706-7220 KLM-2083 160
475002197 HARNESS HNS-2197 (BOARD IN) KLM-1827 40
475002198 HARNESS HNS-2198 (BOARD IN) KLM-1511/12 40
475002550 HARNESS HNS-2550 M.PART 60
475002761 HARNESS HNS-2761 M.PART 40
475002763 HARNESS HNS-2763 M.PART 50
475002764 HARNESS HNS-2764 M.PART 20
475002765 HARNESS HNS-2765 M.PART 40
475002766 HARNESS HNS-2766 M.PART 40
475002767 HARNESS HNS-2767 M.PART 50
475002768 HARNESS HNS-2768 M.PART 70
475002769 HARNESS HNS-2769 M.PART 80
475002770 HARNESS HNS-2770 M.PART 60
475002771 HARNESS HNS-2771 M.PART 110
475002772 HARNESS HNS-2772 M.PART 70
475002776 HARNESS HNS-2776 M.PART 90
475002781 HARNESS HNS-2781 M.PART 50
475002782 HARNESS HNS-2782 M.PART 100
475002784 HARNESS HNS-2784 M.PART 300
475002785 HARNESS HNS-2785 M.PART 100
475002786 HARNESS HNS-2786 M.PART 70
475002787 HARNESS HNS-2787 M.PART 650
3/5
