Korg TRITON proX Service Manual

TRITON pro Parts List Ver1.00
Parts code Parts name and Spesfication PCB No. Unit Price(Yen)
475002811 HARNESS HNS-2811 KLM-1935 10
475002812 HARNESS HNS-2812 M.PART 60
475002813 HARNESS HNS-2813 M.PART 60
475002814 HARNESS HNS-2814 M.PART 90
475002823 HARNESS HNS-2823 M.PART 30
475002824 HARNESS HNS-2824 M.PART 50
475008054 HARNESS HNS-8054 M.PART 10
480010380 DIN JACK YKF51-5041 (3P) M.PART 110
500018500 RUBBER FOOT FF-001 M.PART 10
500024000 X-410 SPONGE SPACER KOC-F40666 M.PART 10
525001300 FERRITE CORE NFT-25 M.PART 80
540007200 WIRE BAND PLT-1M M.PART 10
540008601 SPIRAL CLIP CS-6 M.PART 10
540020200 INLET SOCKET SS-7B M.PART 30
540023800 PLASTIC SUPPORT PS-312 M.PART 10
540023900 CIRCUIT BOARD SPACER MSPLS-6 M.PART 10
575016700 LED SPACER LH-3-2 KLM-1827 10
575018400 LED SPACER LH-5-4.5 L=4.5MM KLM-2086 10
600005100 AC CORD KP-610 GTBS-3 KS-31AY M.PART 830
600005300 AC CORD DC-480-J01 M.PART JP 210
600005400 AC CORD EC-652-E03 M.PART WG 280
600005400 AC CORD EC-652-E03 M.PART FR 280
600005400 AC CORD EC-652-E03 M.PART GE 280
600005700 AC CORD UC-953-J01 M.PART US 210
600005700 AC CORD UC-953-J01 M.PART EX 210
600005700 AC CORD UC-953-J01 M.PART CN 210
600005800 AC CORD SC-111-J01 M.PART AU 250
620024600 X-952 POWER SW KNOB E40304-2 M.PART 20
620034400 X-610 2-LINKAGE B-2-GR M.PART 40
620034500 X-610 2-LINKAGE A-2-GR M.PART 40
620034600 X-631 SVR KNOB E40239-6 M.PART 10
620034700 X-610 ENCODER KNOB E40466-2 M.PART 30
620034800 X610 CONTROL KNOB ASSY M.PART 60
620034900 X610 2-LINKAGE KNOB A-1-GR M.PART 20
620035000 X610 2-LINKAGE KNOB B-1-GR M.PART 20
620035100 4-LINKAGE KNOB B-1-LG E20180 M.PART 10
620035200 4-LINKAGE KNOB A-1-LG E20180 M.PART 10
620035300 4-LINKAGE KNOB A-2-LG M.PART 20
620035900 KNOB P422-9PF(D.GR/W) M.PART 10
641039700 X-115 METAL FITTING OF POWER SW M.PART 70
641041277 X-513/4/5 JACK PLATE 4 C41053 KLM-2084 40
641041326 X-313 FRS ANGLE KOC-C41058 M.PART 40
641041436 GND PLATE M1866-A KOC-C40884-2 KLM-1935 10
641041479 X-013 JACK PLATE 5 KOC0C41132 KLM-2084 40
641041528 X-7100/7110 PCB BOX KOC-C10209 M.PART 390
641041529 X-7100/7110 KB SUPPORT C30528 M.PART 60
641041530 X-7100/7110 OP PLATE C41143 M.PART 20
641041532 X-7100/7110 OP COVER 1 C30526 M.PART 110
641041533 X-7100/7110 OP COVER 2 C30527 M.PART 120
641041534 X-7100/7110 LCD ANGLE C41145 M.PART 20
641041537 X-7110 PANEL KOC-C10205 M.PART 3,810
641041543 X-7110 BOTTOM COVER KOC-C10208 M.PART 1,360
641041544 X-7110 KBF ANGLE KOC-C30529 M.PART 240
644006200 X-011/012 WHEEL SPRING C40848 M.PART 10
646038900 X-011/012 JOYSTICK FRAME M.PART 40
646039000 X-011/012 VR PLATE KOC-E40309 M.PART 20
646039100 X-011/012 WHEEL SUPPORT E40308 M.PART 20
