Kortho Hot Quickcoder User manual
28
Appendix C: Connection diagrams
Control Box Electrical Connection Diagram
PCB supply Hot Quickcoder: Electrical connection diagram HQC
SW 1
NPN
1 = ON
2 = OFF
PNP
1 = OFF
2 = ON
PULSE
1 = OFF
2 = OFF
