Technical data
KDE.4
9 12 9 12
Rated power kW 9 12 9 12
Rated voltage 240V~ 230V~ Rated current A 37,5 50 39,1 52,2
Efciency (at Δt = 30°C and water pressure at 0,4 MPa)
l/min 3,3 4,3 3,3 4,3
Min. connecting wires section mm
2
3 x 10 3 x 6 3 x 10
Max. connecting wires section mm
2
3 x 25 3 x 16
KDE
9 12 15 18 21 24 27
Rated power kW 9 12 15 18 21 24 27
Rated voltage 400V 3~ Rated current A 3x13,0 3x17,3 3x21,7 3x26,0 3x30,3 3x34,6 3x39,0
Rated voltage 380V 3~ Rated current A 3x13,7 3x18,2 3x22,8 3x27,3 3x31,9 3x 36,5 3x41,0
Efciency (at Δt = 30°C and water pressure at 0,4 MPa)
l/min 4,3 5,8 7,2 8,7 10,1 11,6 13,0
Min. connecting wires section mm
2
4x1,5 4x2,5 4x4 4x6
Max. connecting wires section mm
2
4x16
The maximum allowed network impedance Ω 0,43 0,37 0,30
Overall dimension (height without tap set x width x depth
mm 440 x 245 x 120
Weight kg ~5,2
