6 Technical Specifications
6.1 6410N Specifications
INPUTS:
4 digital audio inputs: AES 75; AES/EBU; S/PDIF; TosLink
Optical
OUTPUTS:
2 analog outputs: balanced line out on detachable terminal
blocks; 3.5mm headphone jack
SAMPLE RATE CONVERSION:
32kHz, 44.1kHz, 48kHz, 96kHz
CONVERSION GAIN:
+12dB, +16dB, +20dB,+24dB
BANDWIDTH (+4dBu/-3dBu):
20Hz to 22kHz
MAX. OUTPUT LEVEL:
11.2Vpp @1kHz
S/N RATIO:
88dB
AUDIO THD + NOISE:
-92dB
AUDIO 2nd HARMONIC:
0.003%
CONTROLS:
Input selector buttons, 8 gain switches, headphones level
rotary control knob, 2 LEDs: ON and LINK
POWER CONSUMPTION:
12V DC/1.25A, 150mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 6.95cm x 2.44cm (4.72" x 2.74" x 0.96", W, D, H)
WEIGHT:
0.3kg (0.66lbs.) approx.
INCLUDED ACCESSORIES:
Power supply, mounting bracket
OPTIONAL:
19" rack adapters
Specifications are subject to change without notice at http://www.kramerelectronics.com
6.2 6420N Specifications
INPUTS:
1 analog input balanced line in (10k) on detachable terminal
blocks
OUTPUTS:
4 digital audio outputs: AES 75; AES/EBU; S/PDIF; TosLink
Optical
SAMPLE RATE CONVERSION:
32kHz, 44.1kHz, 48kHz, 96kHz
MAX. INPUT LEVEL:
11.2Vpp @1kHz
CONVERSION GAIN:
-12dB, -16dB, -20dB,-24dB
CONTROLS:
4 sample rate selector switches, system bit selector switch, 8
gain switches, ON LED
COUPLING:
AC
POWER CONSUMPTION:
12V DC/1.25A, 150mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 6.95cm x 2.44cm (4.72" x 2.74" x 0.96", W, D, H)
WEIGHT:
0.3kg (0.66lbs.) approx.
INCLUDED ACCESSORIES:
Power supply, mounting bracket
OPTIONAL:
19" rack adapters
Specifications are subject to change without notice at http://www.kramerelectronics.com
