RC-74DL - Connecting the RC-74DL
4 Connecting the RC-74DL
Always switch off the power to each device before connecting it to your
RC-74DL. After connecting your RC-74DL, connect its power and then
switch on the power to each device.
To connect the RC-74DL, as shown in Figure 3, do the following:
1. Connect the IR outputs as follows:
 Connect an IR emitter to IR OUTPUT 1 and attach the emitter to the
DVD player
 Connect an IR emitter to IR OUTPUT 2 and attach the emitter to the
power amplifier
2. Connect the RS-232 ports (see Section 4.3) as follows:
 Connect RS-232 port 1 to the projector
 Connect RS-232 port 3 to the plasma display
3. Connect the RELAY terminal block connectors as follows:
 Connect RELAY 1 and 2 to the screen
 Connect RELAY 3 and 4 to the lighting system
4. Connect the GPI/O 1 port to a motion detector.
5. Connect the Ethernet port to a network (not shown in Figure 3).
6. Connect the K-NET port to any RC device with K-NET (for example, the
RC-63DL).
