Kramer SID-X2N - Quick Start Guide; Package Contents and Initial Setup

SID - X2N
TECHNICAL SPECIFICATIONS
INPUTS:
1 HDMI, 1 DVI on a Molex 24−pin connector, 1 DisplayPort, 1 UXGA on a 15−pin HD connector, 1
unbalanced stereo audio on a 3.5mm mini jack.
OUTPUT:
1 DGKat on an RJ−45 connector, 1 unbalanced stereo audio on a 3.5mm mini jack.
STANDARDS:
HDMI with x.v.Color™ and 3D; HDCP: works with sources that support HDCP repeater mode.
MAXIMUM STEP - IN
DISTANCE:
50m (164ft) up to 1080p @60Hz.
POWER
CONSUMPTION:
12V DC, 820mA.
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F).
STORAGE
TEMPERATURE:
−40° to +70°C (−40° to 158°F).
HUMIDITY:
10% to 90%, RHL non−condensing.
DIMENSIONS:
18.8cm x 11.3cm x 2.5cm (7.4" x 4.5" x 1") W, D, H.
WEIGHT:
0.48 kg (1.1lbs) approx.
INCLUDED
ACCESSORIES:
Power supply.
OPTIONS:
RK−T2B 19" rack adapter, RTBUS−12, RTBUS−22, SID−X1BP Kit (substitute black top plate for
the SID−X1N that blends with the color of the modular TBUS−10xl), RC−10TB remote contact
closure switch.
