Kramer TP-400FW - 6 Technical Specifications; Table 3: Technical Specifications of the TP-400 FW Firewire Range Extender

Technical Specifications
7
6 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications
1
of the TP-400FW FireWire Range Extender
PORTS: One Front Panel and Rear Panel 6-pin serial 1394 port
2 RJ45 CAT-5 ports
TRANSFER RATE: 100Mbps
IEEE-1394 STANDARDS: IEEE 1394a-2000, IEEE 1394-1995, IEEE 1394b-2002 @ up to 100Mbps
ESD LINE PROTECTION:
IEC 61000-4-2 (ESD) 15kV (air), 8kV (contact), IEC 61000-4-5 (Lightning)
12A (8/20us), and IEC 61000-4-4 (EFT) 40A (5/50ns)
POWER SOURCE: 230 VAC, 50/60 Hz. (115VAC, U.S.A.) 30VA
DIMENSIONS: 22cm x 18cm x 4.5cm (8.7" x 7" x 1.7") W, D, H.
WEIGHT: 1.3 kg (2.9 lbs.) approx.
ACCESSORIES: Power cord
OPTIONS: RK 80 19" rack kit
1 Specifications are subject to change without notice
