Connecting an Audio/Video Distribution System
9
Be sure to place the TP-10 in such a way that the IR SENSOR window will be
in the line-of-sight of your IR remote controller.
You can now operate the video player via its IR remote controller from a
distance.
Figure 5: Audio/Video Distribution System up to 300ft (100m) UTP Cable
CV IN
AIN
UDIO
TP-9
Audio/Video Line Transmitter
S/PDIF
A
NALOG
LO
INE
UT
Y/C IN
TP-10
Video Player
TP-9
Plasma
Display
CV O
UT
AO
UDIO UT
Audio/Video Line Receiver
S/PDIF
A
NALOG
LIN
INE
Y/C O
UT
TP-10
IR
CV
Audio
CV
Audio
IR
