KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
24
12 Technical Specifications
This section includes the technical specifications of the VP-200XLT (see
Table 11), VP-200XLTHD (see Table 12), the VP-300T (see Table 13), the
VP-5T/VP-5THD (see Table 14), and the VP-5R (see Table 15).
Table 11: Technical Specifications
1
of the VP-200XLT (with 30m CAT 5 cable)
INPUTS: 1 XGA on an 15-pin HD connector
OUTPUTS: 1 XGA on an 15-pin HD connector; 1 RJ-45 connector
MAX. OUTPUT LEVEL
2
: 1.9Vpp (XGA), 1.9Vpp (CAT 5)
BANDWIDTH (-3dB): 407MHz (XGA)
RESOLUTION: Up to UXGA
DIFF. GAIN
2
: 0.03% (XGA), 3.5% (CAT 5)
DIFF. PHASE
2
: 0.03Deg (XGA), 0.51Deg (CAT 5)
K-FACTOR
2
: <0.05% (XGA and CAT 5)
S/N RATIO
2
: 74dB (XGA), 71dB (CAT 5)
CONTROLS
2
: LEVEL: –1.5dB to +2.5dB (from VP-200XLT) (XGA); –1dB to +2.5dB (from
VP-200XLT); –7.7dB to +9dB (from TP-120) (CAT 5)
EQ.: 0 to 4.1dB @50MHz (from VP-200XLT) (XGA); 0 to 4dB (from VP-200XLT),
0 to 30.4dB @50MHz (from TP-120) (CAT 5)
COUPLING
2
: DC (XGA), AC (CAT 5)
POWER SOURCE: 12 VDC 140mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98") W, D, H
WEIGHT: 0.3kg (0.67lb) approx.
ACCESSORIES: Power supply
Table 12: Technical Specifications of the VP-200XLTHD (with 30m CAT 5 cable)
INPUTS: 1 XGA on an 15-pin HD connector
OUTPUTS: 1 XGA on an 15-pin HD connector; 1 RJ-45 connector
MAX. OUTPUT LEVEL
2
:
2.4Vpp (XGA), 1.5Vpp (CAT 5)
BANDWIDTH (-3dB): 405MHz (XGA)
RESOLUTION: Up to UXGA, up to 1080p
DIFF. GAIN
2
: 0.03% (XGA), 3.3% (CAT 5)
DIFF. PHASE
2
: 0.03Deg (XGA), 0.3Deg (CAT 5)
K-FACTOR
2
: <0.02% (XGA and CAT 5)
S/N RATIO
2
: 78dB (XGA), 71dB (CAT 5)
CONTROLS
2
: XGA: LEVEL: –1.6dB to +1.9dB; EQ.: 0 to 4dB @50MHz
COUPLING
2
: DC (XGA), AC (CAT 5)
POWER SOURCE: 12V DC, 105mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98”) W, D, H
WEIGHT: 0.3kg (0.67lb) approx.
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
2 For the VP-200XLT to TP-120 SETUP
