VW-9 – Defining VW-9 3x3 Video Wall Driver with Multiviewer
4
Defining VW-9 3x3 Video Wall
Driver with Multiviewer
This section defines VW-9.
Figure 1: VW-9 4x4 Video Wall Driver Front Panel
#
Feature
Function
1
Metal handles (x2)
Rigid metal handles for easy lifting.
2
INPUT Buttons (1 to 4)
After pressing a Window button (above), press an input button to select this input
for that window.
If the wall configuration has only one window, then pressing an input button will
select that input for the wall.
3
WINDOW Buttons (A to D)
Press to select window A, B, C or D.
4
PRESET
CONFIGURATION
Buttons
Press a configuration button to set one of the following presets (each window in
the Multiview mode can be resized and repositioned via the embedded
webpages):
Video wall mode – the video of one source only is presented over
the video wall.
Multiview mode, presenting 1 PiP window over a parent picture in
the video wall.
Multiview mode, presenting 2 PiP windows over a parent picture in
the video wall.
Multiview mode, presenting 3 PiP windows over a parent picture in
the video wall.
Multiview mode, presenting 4 windows over a 3x3 video wall.
5
STO Button
Press, followed by an Input button (1 to 4), to save the current video wall
configuration.
