Replacement Parts
Replacement Parts List Finish/Color Part #
KP46002
KP46025
KP46001
1. Sprayer Head
2. Check Valve
3. Sprayer Hose
4. Handle Assembly
5. Cartridge Cover
7. Cartridge
6. Locking Nut
8. Base Seat Assembly
9. Rubber Washer
10. Metal Washer
11. Mounting Nut
13. 1.8GPM Flow Restrictor
14. Quick Connector
15. EZ-Weight
*Denotes faucet component color options:
CH - Chrome
SFS - Spot Free Stainless Steel
MB - Matte Black
BG - Brushed Gold
WH - White
CH,SFS,MB,BG*
KP46015
KP46022
KP46013
KP46012
KP46021
KP46004
KP46006
12. Mounting Screw
16. Filter Washer
17. Hex Key
BL - Black
CH,SFS,MB,BG*
CH,SFS,MB,BG*
CH,SFS,MB,BG*
CH,SFS,MB,BG*
WH*
KP46007
KP46008
KP46011
KP46010
KP46009
KP46017
1
2
17
KP46024
3
4
5
6
7
8
9
10
11
12
14
13
15
16
18. Mounting Hardware Kit
(includes KP46004,KP46006,
KP46007,KP46008)
KP46038
18
9
