Congratulations on choosing a Kreg Precision Miter Gauge! We have designed this tool to be the finest miter
gauge available. It sets a new standard for accuracy and ease of use.
Be sure to read the instructions and the safety warnings completely before using this tool.
Table of Contents
TABLE OF CONTENTS 1
SAFETY INSTRUCTIONS 2-3
PARTS DIAGRAMS 4-5
SETTING-UP YOUR NEW MITER GAUGE
Adjust the bar to the slot 6-7
Attach the Fence 7
Set the Cursor 8-9
Adding a Sacrificial Fence 10
SETTING THE CUTTING ANGLE
Preset Holes 11
Understanding the Markings on the Scales 12
Resetting the Vernier Scale 13
MICRO-ADJUST FEATURE
Reality Check 14
Setting the Micro-Adjust 14
Setting the Micro-Adjust using Feeler Gauges 14
Setting the Micro-Adjust using a Dial Caliper 14
ACCESSORIES 15
