Krell Industries Foundation 4K - Krell Foundation 4 K UHD Front Panel and Remote Diagram

6Foundation 4K UHD Processor
Front Panel and Remote Diagram
1
8
2
3
4
7
5
6
10
9
1
5
14
12
13
11
1615
6
7
2
3
4
1 Power Standby Button
2 Volume/Navigation Up/Down Button
3 Left/Right Navigation Button
4 Enter Button
5 Source Select Button(s)
6 Surround Mode Select Button
7 Menu Button
8 Front Panel HDMI Input
9 IR Receiver Window
10 ARES Microphone Input
11 Balance Button
12 Krell CD Transport Button
13 Dynamic Range Select Button
14 Channel Adjust Buttons
15 Zone Select Buttons
16 Mute Button
