9. Technical details:
External measuring gauges B110 B110T B220 B220S B2R20 B2R20S
Range [mm] 0-10 0-10 0-20 0-20 0-20 0-20
Scale interval [mm] 0,005 0,005 0,01 0,01 0,01 0,01
Max. permissible errors "G" [mm] 0,01 0,01 0,02 0,02 0,02 0,02
Repeatability limit "r" [mm] 0,01 0,01 0,01 0,01 0,01 0,01
Measuring force (incl. tolerance) [N] 0,6-1,2 0,6-1,2 0,7-1,3 0,7-1,3 0,7-1,3 0,7-1,3
Measuring contact [mm] K Ø 1,5 T Ø 10 K Ø 1,5 Sn-R 0,4 K Ø 1,5 Sn-R 0,4/K Ø 1,5
Max. adjustable OFFSET [mm] ± 0,30 ± 0,30 ± 0,60 ± 0,60 ± 0,60 ± 0,60
Measuring programme
MIN, MAX,
HOLD, TOL
HOLD, TOL
MIN, MAX,
HOLD, TOL
MIN, MAX,
HOLD, TOL
MIN, MAX,
HOLD, TOL
MIN, MAX,
HOLD, TOL
Reference temperature [°C] 20
Operating temperature [°C] +10 bis +30
Storage temperature [°C] -10 bis +50
Display LCD Analog/Digital
Power supply 1,5 Volt Mignon AA, HR6
Operating time approx. 400 hours (Type Duracell Procell, Energizer)
Interface USB + Mitutoyo-Digimatic (accessories)
Protection class IP 63
