KROFtools 9817 - Hydraulic System

11
3
6
/
3. lmmediately find the cause of any abnormalities (excessive noise, overheating, leaking fluids, etc)
4. Pay special attention to lifting parts (cylinders) and safety devices
5. Use all the documentation supplied by the manufacturer (wiring diagrams, etc)
11. HYDRAULIC SYSTEM
1. Oil cylinder 1
2
1
2. Oil cylinder 2
3. Descending valve
4. Slipping valve
5. Throttle valve
4
6. Retaining valve
7. Motor
8. Pump station
5
9. Oil filter
10.Oil Tank
11.safe valve
10
