KROFtools 9817 - Specifications; Working Place

3. SPECIFICATIONS
DIMENSIONS AND OVERALL CLEARANCE DIAGRAM
4. WORKING PLACE
Choose the place that the machine can be installed in compliance with current
work place safety regulations. The floor should not be broken or uneven so that
the machine will be stable and the platform can move freely.
Lifting capacity
3000kg
Max. Lifting height
1000mm
Min. height
110mm
Overall width
1760mm
Platform length
1400-2004mm
Space between platforms
700mm
Lifting time
60 sec
Noise
70db (A) 1m
Operating temperature
10ºC - +50ºC
Work environment:
Closed roam
Power supply
2.2KW
200-240V 50/60Hz 1Ph.
380-415V 50/60Hz 3Ph.
Gross weight
576kg
Net weight
522kg
