4.4 Grounding and equipotential bonding
If the device is not sufficiently electrostatically grounded via the process pipes, an additional
ground connection 1 must be established using the ground terminal. The position of the ground
terminal on the back rail is illustrated below. This connection only ensures electrostatic
grounding of the device and does not meet the requirements for equipotential bonding.
Figure 4-1: Position of the ground terminal
