24
BBlloocckk
NNuummbbeerr
SSttaannddaarrdd--CCoonnffiigguurraattiioonn
function block output: value + status)
KKRR001144551111..GGSSDD
YYPP001144551111..GGSSDD
IIddeenntt--NNoo.. 44551111
DDeeffaauulltt uunniitt::
1 Mass Flow AI-FB kg/s
2 Density AI-FB kg/m3
3 Medium Temperature AI-FB K
4 Mass Totalizer Totalizer-FB kg
5 Volume Totalizer Totalizer-FB m3
6 Mass Totalizer Totalizer-FB kg
7 Volume Flow AI-FB m3/h
8 Concentration 1 AI-FB %
9 Concentration 2 AI-FB %
10 Concentration Mass Flow 1 AI-FB kg/s
11 Concentration Mass Flow 2 AI-FB kg/s
3.4 GSD Files
A “PROFIBUS GSD ZIP” file (e.g. GSD-31777815.zip) including both all KROHNE GSD files and
additional data files can be downloaded from the KROHNE homepage http://www.krohne.com
or contact “KROHNE Marketing”. The GSD file contains information that will be needed for
project planning of the PROFIBUS communication network. The relevant data files (e.g.
MFC300_n.bmp; MFC300_n.dib) must be loaded into the bus configuration system/master sys-
tem before start-up of the bus system.
The MFC300 PROFIBUS MBP Interface is according to the PROFIBUS PA Profile V 3.01. The
device supports two Ident-No.:
• Ident-No. “4511hex” belongs to the KR014511.GSD / YP014511.GSD and includes the com-
plete functionality concerning the cyclic data exchange of the coriolis mass flow meter
MFC300.
• The application of the manufacturer independent Ident-No. “9742hex” (GSD file
“PA139742.GSD”) provides interchange ability of devices, i.e. an exchange of coriolis mass
flow meters of different vendors.
Please follow the instructions in the manual of the host supplier when installing the GSD File
you need and the additional files (MFC300_n.bmp and MFC300_n.dib) into the PLC. If separated
by the bus configuration system the device entry of the MFC300 PROFIBUS MBP Interface with
PA Profile 3.01 will be located within the slave family PROFIBUS PA.
33..44..11 MMaannuuffaaccttuurreerr ssppeecciiffiicc GGSSDD ffiilleess:: KKRR001144551111..GGSSDD && YYPP001144551111 GGSSDD
The KR014511.GSD file is for use with the standard DP/PA coupler and the YP014511.GSD file
is for use with the transparent DP/PA coupler SK2/SK3 of Pepperl & Fuchs (up to 12 MBaud on
the DP segment)
Note: For devices with MBP interface there are always two types of GSD files in our GSD com-
pilation:
• One standard GSD file for a standard DP/PA segment coupler: file name: “KR….GSD”
• One special GSD file specific for the segment coupler SK2/SK3 of Pepperl & Fuchs file
name: “YP….GSD”
It should be noted that both GSD files suport device functionality as described below:
