? The drive shaft moves constantly?
! Current signal fluctuates.
Check control loop, if possible attenuate it.
Increase the hysteresis and filtering in BCSoft.
! 3-point step signal commands too many changes
of direction.
! Check/adjust the 3-point step controller.
? No communication possible between PC
and IC40?
! Incorrect interface used on the PC.
Set the interface to the correct configuration us-
ing BCSoft– see page5 (Commissioning).
! Opto-adapter not positioned correctly.
Position the magnetic head of the opto-adapter
in the circle provided.
! Optical waveguide bent.
Carefully align the optical waveguides on the
circuit board with the marking on the housing
cover (circle).
! Housing cover not correctly secured.
Close the housing and tighten all the screws.
! Film on the marking on cover (circle) dirty or dam
-
aged.
Clean the film; if it is damaged, replace the cover.
! Opto-adapter defective.
Check the adapter using the BCSoft test function.
Replace the opto-adapter.
? The parameters cannot be set in the soft-
ware?
! No writing access granted.
Enter passcode for writing access (see BCSoft
operating instructions).
? Unit does not react to signal change– the
blue LED flashes quickly?
! The unit is in Manual mode.
Deactivate Manual mode in BCSoft or disconnect
device from the mains.
? The motor and drive shaft of the actuator
no longer function as required?
! The gear is defective.
Remove the unit and return it to the manufacturer.
! The selected nominal valve size is too big and
has reduced the service life of the mechanical
components due to excessive stress.
Check the system design.
Adjust the valve size and/or actuator.
! Gear load is too great.
Check the torque – see page 9 (Technical
data).
? Feedback potentiometer indicates incorrect
values?
! Connections on the terminal strip mixed up.
Check the contact assignment on the terminal
strip.
! Incorrect potentiometer utilization.
Utilize the potentiometer as a voltage divider.
! The windings in the potentiometer are defective.
Remove the unit and return it to the manufacturer
for inspection.
? Software problem and/or problem with set-
tings?
! Software version obsolete.
The current software and operating instructions
can be downloaded from www.docuthek.com,
see page5 (Accessories).
? Is it not possible for the fault to be eliminated
with the measures described above?
Remove the unit and return it to the manufacturer
for inspection.
