28
T-Product · BCU 465 · 2006 April
Troubleshooting
Fault codes (?), Possible Causes (!) and Solutions ()
? The display flashes and dis-
plays 01?
! The BCU has detected a flame
signal simulation without the
burner having been ignited (ex
-
traneous signal)
! The UV tube in the UV sensor
UVS is defective and permanent
-
ly indicates an extraneous signal
Exchange UV tube, order part #
04065304 – note the operating
instructions for the UV sensor
! Flame signal through ceramic in-
sulation
Increase value of parameter 04
in order to adapt the switch-off
threshold of the flame amplifier
? The display flashes and dis
-
plays 0?
! The BCU has detected that the
Proof of Closure Switch (OCS)
input has got no proof of closure
signal in standby position.
Make sure that the wiring is cor
-
rect. The BCU needs line voltage
when valve is closed and no volt
-
age signal when valve is opened.
If the wiring is correct, check the
switch and the valve for proper
operation. Remove the valve im
-
mediately if you have any doubt
of correct close position.
? The display flashes and dis
-
plays X?
! The BCU has got no information
that the OCS contact is still open.
Make sure that the wiring is cor
-
rect. The BCU needs line voltage
when valve is closed and no volt
-
age signal when valve is opened
during start-up.
If the wiring is correct, check the
switch and the valve for proper
operation. Remove the valve im
-
mediately if you have any doubt
of correct operation.
? At start-up, the display flash
-
es and indicates 2?
! The BCU has got no informa-
tion that the OCS contact has
opened.
Make sure that the wiring is cor
-
rect. The BCU needs line voltage
when valve is closed and no volt
-
age signal when valve is opened
during start-up.
If the wiring is correct, check the
switch and the valve for proper
operation. Remove the valve im
-
mediately if you have any doubt
of correct operation.
? At start-up – no ignition spark
occurs – the display flashes
and indicates 02
?
! Ignition cable is too long.
Shorten it to 1 m (maximum 5
m).
! Distance between ignition elec
-
trode and burner head is too
large.
Set a distance to 2 mm maxi
-
mum.
! Ignition cable not making contact
in the electrode plug.
Screw the cable on firmly.
! Ignition cable has a short-circuit
to ground.
Check the cable along its length
and clean the ignition electrode.
? At start-up – no gas supply
– the display flashes and indi
-
cates 02?
! The gas valve V1 is not opening.
Check the electrical power sup
-
ply to the gas valve.
! There is still air in the pipe (ex
-
ample: after installation work has
been completed or when the
system has not been in opera
-
tion for a long period of time).
Reset repeatedly until gas line
fills with gas.
