7 Terminal menus
7.25 Menu 15 "Settings"
66
RP701-10 , RP701-11 , RP701-20 , RP701-21 , RP701-30 , RP701-31 , RP701-40 , RP701-41 , RP701-51
Comfort 1.0_en
Dimension X Dimension Y
Net wrapping 410mm 365mm
Chamber film wrapping 400mm 370–375mm
 Press the key
or until the tying actuator retracts far enough and the dimensions
X and Y from the table above are achieved.
 Press
.
Æ The set position is saved.
Setting the tying position
RP000-045
The tying position must not be set separately as it results from the cutting position and the feed
position. The tying position has been set optimally when the rope (3) is not tensioned and the
roll (1) is positioned in front of the ratchet mechanism.
If the rope (3) is tensioned and the roll (1) is not positioned in front of the ratchet mechanism (2),
check and reset the cutting position and the feed position.
