3 Id.: 17-16-13-2960-03 | 7.2017
1 Spatial Corrector KT-2
The spatial corrector KT-2 is user friendly and allows measurements and displays of room temperature,
adjustments of desired room temperature, the status of the heat circuit, settings of the circuit, status of
alerts, external temperature and clock.
2 Safety alerts
The spatial corrector must be connected properly. An incorrect connection can damage the
device. The manufacturer is not responsible for damage caused by incorrect installation
and/or improper use.
3 Installation
The Spatial corrector KT-2 must be installed in a room where the temperature is closest to your desired
average temperature of other rooms (hallway, living room).
The spatial corrector KT-2 is designed for installation on a flush-mounted electrical socket 3M
(GW 24 403 PM).
The spatial corrector is used for fixed installation in closed and dry rooms.
Recommended mounting height is between
1, 2 - 1, 5 m from the ground.
Do not expose the spatial corrector KT-2 to
direct sunlight, do not install it in the area of
air currents or air heated in any other way
(e.g. over electric cookers, refrigerators,
etc., or in the area of direct radiation heat of
radiators), because the heat affects the
control characteristics.
Do not install the spatial corrector KT-2 as
part of other electrical equipment, e.g.
dimmers, a possible heat emission could
affect proper operation.
4 Installation
Mount the spatial corrector KT-2 in:
A flush-mounted electrical socket 3M, H x W x D 106 x 74 x 48 mm
