Kronoterm KT-2 - Operation and Setup; Initial Device Connection; Control Loop Setup; Synchronization Process

5 Id.: 17-16-13-2960-03 | 7.2017
7 Initial connection
When connecting the data cable to the control
panel fort the first time, the regulating circuit
setup screen is displayed.
8 SETUP OF CONTROL LOOP
Set the desired heating circuit with the keys
and . Press to confirm the settings.
The control panel confirms valid settings with
a multi-tone beep.
9 SYNCHRONISATION
The device is synchronising, wait a few
minutes …
After a successful synchronisation, the control
panel is ready for use (see Qick user guide).
NOTE
Only one spatial corrector can control an individual control loop. Incorrect operation occurs if
two spatial correctors are installed on the same control loop.
10 CHNGE OR RESETTING OF CONTROL LOOP
NOTE
The recommended way to disconnect the power supply is by disconnecting the electrical
fuse.
