17
Pins definition of connecting terminal on the board
Relaycard electrical parameter
max Type
Relaycardcontact
(Max Switched Voltage)
AC:120V
DC:24V
AC:120V
DC:5~12V
(Max Switched Current)
AC:1A
DC:1A
AC:1A
DC:1A
