-25-
Pin Assignments
Pin RS-232 signals IN/OUT
1,2,7,8 NC
3 RxD IN
6 TxD OUT
4,5 GND
Baud Rate information
Baud rate - 115200
Data bits - 8
Parity - None
Stop bit - 1
Flow control – None
