23 TECHNICAL DATA
160
Sport 1 turn
Rebound damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Spring preload 7 mm (0.28 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 57 … 63 N/mm (325 … 360 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 60 … 66 N/mm (343 … 377 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 63 … 69 N/mm (360 … 394 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 37 mm (1.46 in)
Riding sag 110 mm (4.33 in)
Fitted length 415 mm (16.34 in)
Shock absorber fluid ( p. 164) SAE 2.5
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, activated carbon filter
(150 EXC TPI EU)
- 5 Nm (3.7 lbf ft)
Screw, fuel pump on fuel tank EJOT PT
®
K60x25‑Z 2.5 Nm (1.84 lbf ft)
Screw, hose clip, inlet sleeve 2.8 Nm (2.07 lbf ft)
Screw, intake air temperature sen-
sor
EJOTDELTA PT
®
45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, oil fill level sensor G 3/4 " 7 Nm (5.2 lbf ft)
Screw, oil pump holder on oil tank EJOTDELTA PT
®
45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, radiator hoses clip 2.4 Nm (1.77 lbf ft)
Nut, throttle cable wire on throttle
valve body
M4 3 Nm (2.2 lbf ft)
Screw, emergency OFF switch
(150 EXC TPI EU)
M4 0.4 Nm (0.3 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, throttle valve body cover M4 2.6 Nm (1.92 lbf ft)
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, brake line guide for link
fork
M5 5 Nm (3.7 lbf ft)
Screw, ground wire in tail section M5 5 Nm (3.7 lbf ft)
Screw, light switch (150 EXC
TPI EU)
M5 1 Nm (0.7 lbf ft)
