KTM 250 sx 1994 User Manual

Repair manual 250 / 300 / 380 Art No 3206004 -E
ELECTRICAL
CHECKING THE VOLTAGE REGULATOR-RECTIFIER (SHINDENGEN) . . .7-2
CHECKING THE VOLTAGE REGULATOR (KOKUSAN) . . . . . . . . . . . . .7-2
CHECKING THE VOLTAGE REGULATOR (TYMPANIUM) . . . . . . . . . . .7-2
CHECKING THE CAPACITOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3
IGNITION COIL (SEM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3
IGNITION COIL (KOKUSAN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3
CDI UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3
CHECKING THE VOLTAGE REGULATOR (MOD. 2000) . . . . . . . . . . . .7-4
CHECKING THE CAPACITOR (MOD. 2000) . . . . . . . . . . . . . . . . . . . .7-4
STATIC IGNITION VALUES 250 - 380 SX, EXC . . . . . . . . . . . . . . . . . .7-5
STATIC GENERATOR VALUES 250 - 380 EXC . . . . . . . . . . . . . . . . . . .7-7
STATIC IGNITION AND GENERATOR VALUES 250 MXC, EXC (USA) . .7-9
INDEX
7-1C
7

KTM 250 sx 1994 Specifications

General

Engine Type	Single-cylinder, two-stroke
Displacement	249 cc
Bore x Stroke	66.4 mm x 72 mm
Cooling System	Liquid-cooled
Ignition System	CDI
Lubrication	Premix
Starting System	Kick start
