KTM 250 SX 2019 User Manual

SERVICE WORK ON THE CHASSIS 11
65
K01133-10
–
Mount and tighten screw
1
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
11.22 Removing the air filter box cover
Condition
The air filter box cover is secured.
– Remove the seat. ( p. 64)
K01226-10
–
Remove screw
1
.
K01227-10
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.
K01225-10
Condition
The air filter box cover is not secured.
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.

KTM 250 SX 2019 Specifications

General

Displacement	249 cc
Bore x Stroke	66.4 mm x 72 mm
Starter	Kickstarter
Transmission	5-speed
Ignition	Kokusan
Ground Clearance	375 mm
Seat Height	950 mm
Engine Type	2-stroke
Clutch	Wet, multi-disc clutch
Frame Type	Central double-cradle type 25CrMo4 steel
Front Suspension	WP XACT 48 mm fork
Rear Suspension	WP XACT shock absorber with linkage
Front Brake	Disc brake, 260 mm
Rear Brake	Disc brake, 220 mm
Fuel Tank Capacity	7.5 liters
