SERVICE WORK ON THE CHASSIS 11
65
K01133-10
–
Mount and tighten screw
1
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
11.22 Removing the air filter box cover
Condition
The air filter box cover is secured.
– Remove the seat. ( p. 64)
K01226-10
–
Remove screw
1
.
K01227-10
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.
K01225-10
Condition
The air filter box cover is not secured.
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 300 XC 2019 and is the answer not in the manual?

KTM 300 XC 2019 Specifications

General IconGeneral
Displacement293.2 cc
Bore x Stroke72 mm x 72 mm
StarterElectric starter
Transmission6-speed
Rear SuspensionWP Xplor PDS shock absorber
Fuel Tank Capacity9.5 liters
Ground Clearance370 mm
CoolingLiquid cooled
Engine Type2-stroke
FrameCentral double-cradle type 25CrMo4 steel
Front SuspensionWP XPlor 48
Front BrakeDisc brake, Ø 260 mm
Rear BrakeDisc brake, Ø 220 mm
Seat Height960 mm
Fuel SystemKeihin carburetor
