KTM 450 XCR-W USA User Manual

WIRING DIAGRAM 161
Components
1 Battery
2 Generator
3 Ignition coil
4 Pulse generator
5 Voltage regulator/rectifier
6 Electric starter button
7 Starter relay with fuse
8 Starter motor
9 Light switch, horn button, short circuit button
10 Throttle valve sensor TPS
11 Ignition curve plug connection
12 CDI controller
13 Headlight
14 Parking light
15 Brake / tail light
16 Licence plate lamp
17 Speedometer
18 Wheel speed sensor
19 Tripmaster switch (optional)
20 Flasher switch
21 Flasher relay
22 Left front flasher
23 Left rear flasher
24 Right front flasher
25 Right rear flasher
26 Horn
27 Front brake light switch
28 Rear brake light switch
29 High beam indicator light
30 Flasher indicator light
31 Plug connector for radiator fan (optional)
Cable colors
bl black
bl-wh black-white
br brown
br-bl brown-black
bu blue
bu-wh blue-white
gn green
gr gray
or orange
pu violet
re red
re-bl red-black
re-wh red-white
wh white
wh-gn white-green
wh-re white-red
ye yellow
ye-bl yellow-black
ye-re yellow-red

KTM 450 XCR-W USA Specifications

General

Transmission	6-speed
Fuel Tank Capacity	8.5 L
Ignition	Keihin EMS
Compression Ratio	12.75:1
Starter	Electric starter
Lubrication	Pressure lubrication with 2 oil pumps
Subframe	Aluminum
Suspension Travel Front	300 mm
Suspension Travel Rear	310 mm
Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	95 mm x 63.4 mm
Fuel System	Keihin EMS
Front Suspension	WP Xplor 48
Rear Suspension	WP Xplor PDS shock absorber
Front Brake	Disc brake
Rear Brake	220 mm disc
Cooling	Liquid cooled
Clutch	Wet multi-disc clutch, hydraulically operated
Frame	Central tube frame made of chrome molybdenum steel
