23 TECHNICAL DATA
250
Remaining nuts, chassis M10 50 Nm (36.9 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, side stand pivot M10 35 Nm (25.8 lbf ft)
Screw, front footrest bracket /
engine bearer
M10x1.25 49 Nm (36.1 lbf ft)
Screw, side stand bracket M10x1.25 33 Nm (24.3 lbf ft)
Loctite
®
243™
Nut, rear wheel spindle M14x1.5 90 Nm (66.4 lbf ft)
Nut, swingarm pivot M14x1.5 100 Nm (73.8 lbf ft)
Screw, steering head, top M16x1.5 53 Nm (39.1 lbf ft)
Loctite
®
204™
Lambda sensor M18x1.5 19 Nm (14 lbf ft)
Swingarm bearing adjusting ring M22x1 Tighten and ensure that there is no
play
Nut, steering head M30x1 1.
55 Nm (40.6 lbf ft)
2. Loosen (counterclockwise)
2 turns
3.
5 Nm (3.7 lbf ft)
