WHEELS, TIRES 14
149
E00668-10
–
Clean the thread of the wheel spindle and screw
3
.
– Grease wheel spindle.
Long-life grease ( p. 241)
– Position the front wheel and insert the wheel spindle.
The brake linings are correctly positioned.
–
Mount and tighten screw
3
.
Guideline
Screw, front wheel
spindle
M8 26 Nm (19.2 lbf ft)
–
Position wheel speed sensor
4
in the hole.
– Position reflector.
–
Mount and tighten screw
5
.
Guideline
Screw, wheel speed
sensor holder
M6 8 Nm (5.9 lbf ft)
–
Mount and tighten screws
6
.
– Operate the hand brake lever repeatedly until the brake lin-
ings are in contact with the brake disc and there is a pressure
point.
– Take the motorcycle off the front lifting gear. ( p. 103)
– Remove the rear of the motorcycle from the lifting gear.
( p. 100)
