12 SERVICE WORK ON THE CHASSIS 100
G00963-10
– Position the side cover.
–
Mount and tighten screws
.
Guideline
Screw, side cover M6 7 Nm (5.2 lbf ft)
–
Push on the side cover in area
.
The holding lug engages in the drilled hole on the front spoiler.
–
Mount and tighten screws
.
Guideline
Screw, side cover on front mask M6 6 Nm (4.4 lbf ft)
L02198-10
–
Mount expanding rivet
.
