6 CONTROLS 23

6.3 Throttle grip

L02112-11

The throttle grip



is fitted on the right side of the handlebar.

6.4 Horn button

L02113-10

The horn button



is fitted on the left side of the handlebar.

Possible states

• Horn button in neutral position

• Horn button pressed – The horn is operated in this position.
