15 ELECTRICAL SYSTEM 135
Fuse (75011088015) ( p. 185)
Tip
Replace spare fuse
in the fuse box so that it is available if needed.
– Mount the protection cap.
L02158-11
To change the fuse of the ABS return pump:
–
Take off the protection cap and remove fuse
.
Warning
Fire hazard The electrical system can be overloaded if the wrong fuses are
used.
– Use only fuses with the prescribed amperage. Never bypass or repair
fuses.
– Use spare fuses with the correct rating only.
Fuse (90111088025) ( p. 185)
Tip
Replace spare fuse
in the fuse box so that it is available if needed.
– Mount the protection cap.
Finishing work
– Mount the battery cover. ( p. 94)
– Mount the front rider's seat. ( p. 82)
