23 TECHNICAL DATA 182

Screw, locking lever M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, oil pump M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, retaining bracket, shaft seal ring,

clutch cover

M6 11 Nm (8.1 lbf ft) Loctite

243™

Screw, shift drum locating M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, starter motor M6 12 Nm (8.9 lbf ft) –

Screw, timing chain tensioner M6 12 Nm (8.9 lbf ft) –

Screw, timing chain tensioning rail M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, valve cover M6 12 Nm (8.9 lbf ft) –

Screw, water pump cover M6 12 Nm (8.9 lbf ft) –

Nut, conrod bearing (RC 125) M7 24 Nm (17.7 lbf ft) –

Screw, conrod bearing (RC 200) M7 24 Nm (17.7 lbf ft) –

Nut, exhaust flange M8 22 Nm (16.2 lbf ft) –

Screw, balancer shaft gear (RC 125) M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, balancer shaft gear (RC 200) M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, camshaft drive sprocket M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, return spring, quick shifter M8 12 Nm (8.9 lbf ft) Loctite

243™

Stud, exhaust flange M8 22 Nm (16.2 lbf ft) –

Cylinder head screw (RC 125) M10 Step 1

25 Nm (18.4 lbf ft)

Step 2

50 Nm (36.9 lbf ft)

Thread is oiled, head flat is

greased

Oil pressure sensor M10 14 Nm (10.3 lbf ft) –

Rotor screw M10 46 Nm (33.9 lbf ft) Loctite

243™
