12 SERVICE WORK ON THE CHASSIS 97

G00976-13

–

Mount and tighten screw



.

Guideline

Screw, front spoiler, right, on footrest

bracket

M6 7 Nm (5.2 lbf ft)

G01029-11

–

Mount and tighten screws



.

Guideline

Screw, front spoiler M6 7 Nm (5.2 lbf ft)

Finishing work

– Install the left side cover. ( p. 99)

– Install the right side cover. ( p. 102)
