4 TECHNICAL DATA
14
Screw, chain sliding guard M6 7 Nm (5.2 lbf ft)
Screw, compensating tank M6 8 Nm (5.9 lbf ft)
Screw, engine sprocket cover on
frame
M6 8 Nm (5.9 lbf ft)
Screw, foot brake cylinder M6 9 Nm (6.6 lbf ft)
Loctite
®
243™
Screw, footrest bracket M6 7 Nm (5.2 lbf ft)
Screw, front fairing M6 7 Nm (5.2 lbf ft)
Screw, front fairing structure on
headlight bracket
M6 7 Nm (5.2 lbf ft)
Screw, front fender M6 7 Nm (5.2 lbf ft)
Screw, front fender, top side M6 7 Nm (5.2 lbf ft)
Screw, front seat fixing M6 6 Nm (4.4 lbf ft)
Screw, front spoiler bottom front M6 6 Nm (4.4 lbf ft)
Screw, front spoiler rear M6 6 Nm (4.4 lbf ft)
Screw, front spoiler retaining
bracket, rear, on engine
M6 6 Nm (4.4 lbf ft)
Screw, front spoiler, right, on
footrest bracket
M6 6 Nm (4.4 lbf ft)
Screw, ground cable, on frame M6 7 Nm (5.2 lbf ft)
Screw, handlebar stub M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, ignition coil M6 9 Nm (6.6 lbf ft)
Screw, ignition lock M6 11 Nm (8.1 lbf ft)
Screw, license plate holder on
license plate bracket
M6 7 Nm (5.2 lbf ft)
Screw, magnetic holder on side
stand
M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, mirror holder M6 9 Nm (6.6 lbf ft)
Screw, passenger seat M6 7 Nm (5.2 lbf ft)
Screw, radiator air inlet, on frame M6 6 Nm (4.4 lbf ft)
Screw, radiator shield M6 6 Nm (4.4 lbf ft)
Screw, rear ABS sensor wheel M6 8 Nm (5.9 lbf ft)
Screw, rear fender M6 7 Nm (5.2 lbf ft)
Screw, retaining bracket, EFI con-
trol unit
M6 6 Nm (4.4 lbf ft)
Screw, rollover sensor M6 7 Nm (5.2 lbf ft)
Loctite
®
243™
Screw, shift lever linkage M6 11 Nm (8.1 lbf ft)
Loctite
®
243™
Screw, side cover M6 6 Nm (4.4 lbf ft)
Screw, side cover on front fairing M6 6 Nm (4.4 lbf ft)
Screw, voltage regulator M6 7 Nm (5.2 lbf ft)
Screw, voltage regulator holder M6 11 Nm (8.1 lbf ft)
Screw, wheel speed sensor holder M6 8 Nm (5.9 lbf ft)
Screw, windshield M6 7 Nm (5.2 lbf ft)
Exhaust clamp M8 20 Nm (14.8 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
