KTM RC 390 2016 - 4 Technical Data; 4.1 Chassis Tightening Torques

4 TECHNICAL DATA
13
4.1 chassis tightening torques
Screw, chain guard EJOT PT
®
K60x30 4 Nm (3 lbf ft)
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft)
Remaining screws, chassis M4 4 Nm (3 lbf ft)
Screw, EFI control unit M4 3 Nm (2.2 lbf ft)
Nut, reflector on retaining plate M5 5 Nm (3.7 lbf ft)
Nut, retaining plate on license
plate holder
M5 4 Nm (3 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, ABS hose clamp M5 5 Nm (3.7 lbf ft)
Screw, anti-rotation lock, handle-
bar stub
M5 4 Nm (3 lbf ft)
Screw, battery compartment M5 4 Nm (3 lbf ft)
Screw, chain guard M5 7 Nm (5.2 lbf ft)
Loctite
®
204™
Screw, cover in front of battery
compartment
M5 4 Nm (3 lbf ft)
Screw, fuel pump M5 5 Nm (3.7 lbf ft)
Screw, fuel tank cover M5 4 Nm (3 lbf ft)
Screw, side stand switch M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, tail end lower part M5 4 Nm (3 lbf ft)
Cap bolt, footrest M6 9 Nm (6.6 lbf ft)
Nut, foot brake lever adjustment M6 9 Nm (6.6 lbf ft)
Nut, license plate holder M6 7 Nm (5.2 lbf ft)
Nut, shift rod M6 10 Nm (7.4 lbf ft)
Nut, shift rod M6LH 10 Nm (7.4 lbf ft)
Nut, tail light M6 7 Nm (5.2 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 9 Nm (6.6 lbf ft)
Screw, ABS module on ABS mod-
ule retaining bracket
M6 7 Nm (5.2 lbf ft)
Loctite
®
243™
Screw, ABS module retaining
bracket on silent block
M6 7 Nm (5.2 lbf ft)
Screw, air filter box lid M6 6 Nm (4.4 lbf ft)
Screw, air filter box, on frame M6 6 Nm (4.4 lbf ft)
Screw, battery compartment M6 6 Nm (4.4 lbf ft)
Screw, brake fluid container, front
brake
M6 8 Nm (5.9 lbf ft)
Screw, brake fluid reservoir, rear
brake
M6 8 Nm (5.9 lbf ft)
Screw, brake line guide on bottom
triple clamp
M6 7 Nm (5.2 lbf ft)
Loctite
®
243™
Screw, cable holder, side stand
switch
M6 9 Nm (6.6 lbf ft)
Loctite
®
243™
Screw, chain guard M6 6 Nm (4.4 lbf ft)
