1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM RC 390 2016 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Transmission	6-speed
Cooling System	Liquid cooled
Rear Suspension	WP monoshock
Rear Brake	230 mm disc, single-piston caliper
ABS	Bosch 9MB two-channel ABS
Seat Height	820 mm
Fuel Tank Capacity	10 liters
Dry Weight	147 kg
Compression Ratio	12.6:1
Starter	Electric starter
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Power	32 kW (44 hp) @ 9, 500 rpm
Torque	35 Nm
Fuel System	Electronic Fuel Injection (EFI)
Front Suspension	WP USD 43 mm
Frame	Steel trellis frame
