Kuat PIVOT v2 - Rack Installation

2 Insert hitch pin and
secure with hitch lock.
1 Slide Pivot v2 into hitch and align the hitch pin holes.
3 Fully tighten FlatLock
TM
hitch cam
using the provided 8mm hex key.
Rack Installation
1 Slide accessory rack into the Pivot v2
and align the hitch pin holes.
2 Secure accessory rack
using hitch pin.
3 Tighten accessory rack.
Installing Pivot v2 into Hitch
1
3
Do not exceed 25 ft/lbs (34Nm).
2
™
™
™
WARNING
