OPERATING THE TRACTOR18
BAdjustment of Foldable ROPS
A Adjust free fall of the ROPS upper frame regularly.
A If you feel less friction when folding the ROPS, remove
the cotter pin (1), tighten the nut (2) until you feel the
right friction in the movement and then replace the
cotter pin.
STARTING
BOperator's Seat
To avoid personal injury:
A Make sure that the seat is completely secured
after each adjustment.
A Do not allow any person other than the driver to
ride on the tractor.
C Position adjustment
Pull in the position adjust lever and slide the seat
backward or forward, as required. The seat will lock in
position when the lever is released.
A After adjusting the operator's seat, be sure to check
that the seat is properly locked.
(1) Cotter pin
(2) Nut
1. Adjusting the operator's position.
(1) Seat
(2) Position adjust lever
(3) Arm rest
(A) "PULL IN"
